QUICK FEATURES ON STAMPEDE (#37054-61):
NEW Factory-installed front and rear LED lighting
NEW ProGraphix® paint
Includes battery and charger
4-amp DC Peak Detecting Fast Charger
Traxxas 3000 mAh 8.4V 7-cell NiMH battery with iD®
TQ™ 2.4GHz radio system
Waterproof electronics for all-weather driving
48+kph!*
Titan® 12-turn 550 motor
Powerful XL-5 waterproof electronic speed control
Traxxas' exclusive patented Training Mode
Brushless-Ready metal gear Magnum 272™ transmission
100% Fully assembled and Ready-To-Race®
STAMPEDE (#36054-61) SPECS:
Length: 428 mm
Front Track: 324 mm
Rear Track: 324 mm
Weight: 1.85 kg
Height (overall): 241 mm
Wheelbase: 270 mm
Front Shock Length: Long
Rear Shock Length: XXLong
Front Tires (pre-glued): Talon™ 2.8"
Rear Tires (pre-glued): Talon™ 2.8"
Front Wheels: 2.8" Mirror-Chrome (All-Star™)
Rear Wheels: 2.8" Mirror-Chrome (All-Star™)
Electronic Speed Control: XL-5™ Electronic Speed Control
Motor (electric): Titan® 12T 550 (12-Turn)
Steering Servo: #2056 High Torque Waterproof
Transmitter: TQ 2.4GHz Radio
Receiver: #6519 3-Channel Micro
Gear Ratio (internal): 2.72 (final drive: 12.34)
Differential Type: Planetary
Gear Pitch: 48-Pitch
Transmission: Magnum 272™
Steering: Single Point
Chassis Type: Modified Tub
Chassis Material: Composite Nylon
Top Speed: 48+kph**
Skill Level: 1
Battery Tray Dimensions*: 164 x 46 x 26 mm
Included Charger: 4-amp 12V DC Peak Detecting Fast Charger
Included Batteries: Traxxas 7-cell NiMH battery with iD®
Required Batteries: 4 "AA" (transmitter)
*Battery expansion kit is available (#3725X)
**With 7-cell battery and included optional 21-tooth pinion gear
XL-5 (WATERPROOF) ESC SPECIFICATIONS:
Input voltage: 4-7 Cells (4.8 to 8.4 Volts DC)
Case Size: 31 x 55 x 15.5 mm
Motor Limit: 15-turns** (540 Size) / 12-turns** (550 Size)
BEC Voltage: 6.0 VDC
BEC Current: 1A
Power Wire: 14 Gauge
Input Harness Wire: 26 Gauge
Low Voltage Detection (LVD): 2-Stage indicators, switchable (on or off)
Thermal Protection: Thermal shutdown
Single-button setup: Yes, Traxxas EZ-Set®
Profile selection:
Sport Mode: 100% FWD, 100% brakes, 100% REV
Race Mode: 100% FWD, 100% brakes, no REV
Training Mode*: 50% FWD, 100% brakes, 50% REV
*Patented
**Properly Geared
